F 250 4WD Super Duty V10-6.8L (2002)
Steering Gear: Service and Repair
Removal and Installation
Steering Gear
Special Tool(s)
Special Tool(s)
Removal and Installation
All vehicles
1. Remove the air cleaner assembly.
Vehicles with 7.3L engine
2. Loosen the clamps and remove the air cooler outlet duct.
3. Press the brake pedal several times to discharge the accumulator.
All vehicles
4. Disengage the steering coupling shield from the line fitting and slide upwards on the steering shaft.
