F 350 2WD Pickup V8-460 7.5L VIN G EFI (1997)
EGR Valve Position Sensor: Electrical Specifications
Multiport Fuel Injection (49-State)
Multiport Fuel Injection (49-State)
Voltage values calculated for VREF = 5.0v. These values may vary +/- 15% due to sensor and VREF variations.
Voltage
% EGR
0
0.40 V
10
0.75 V
20
1.10 V
30
1.45 V
40
1.80 V
50
2.15 V
60
1.50 V
70
2.85 V
80
3.20 V
90
3.55 V
100
3.90 V
