F 450 2WD Super Duty V10-6.8L VIN V (2005)
Wheel Speed Sensor: Service and Repair
Wheel Speed Sensor - Rear
Wheel Speed Sensor - Rear
Removal and Installation
CAUTION: Clean off dirt and debris that may have collected around the rear axle speed sensor before removal to prevent fluid contamination.
1. Disconnect the battery.
2. With the vehicle in NEUTRAL, position it on a hoist.
3. Disconnect the rear axle speed sensor electrical connector.
4. NOTE: Do not apply force to the plastic rear axle speed sensor connector.
Remove the bolt and the rear axle speed sensor.
5. To install, reverse the removal procedure.
