Front Door Exterior Handle: Service and Repair

REMOVAL

1. Remove the front door trim panel.

2. Peel back the watershield.

CAUTION:  Do not touch the adhesive surface as rebonding will be impaired.

3. Loosen the lock cylinder cover screw.

4. Remove the lock cylinder exterior cover.

5. Detach the exterior door handle.
