Focus L4-2.0L VIN N (2006)
Brake Pedal Assy: Service and Repair
Brake Pedal
Brake Pedal
Removal and Installation
1. Remove the 4 screws, release the fastener and position the instrument panel lower panel aside.
^
To install, tighten to 9 Nm (80 inch lbs.).
2. Disconnect the hood release cable and the data link connector (DLC) from the instrument panel lower panel and remove the lower panel.
^
Loosen the hood release cable nut.
^
To install, tighten to 20 Nm (15 ft. lbs.).
3. Disconnect the electrical connectors and twist to remove these switches:
^
Speed control deactivation switch (if equipped)
^
Stop lamp switch
^
Clutch position switch (if equipped)
