Focus L4-2.0L VIN N (2006)
C1033
Component and Connector Information
Connector views show the views of the pins and/or cavities of all connectors. The pin and cavity sides are shown separately as if the connector were
disconnected. The color of the connector housing is indicated next to the connector number when available. The harness causal number is located
above the component name and below the connector number or above the connector face itself. Wiring harness designations are listed in Component
Location Charts. Circuit function charts are located below each connector.
Component Location Views show the components and their connecting wires as they can be found on the vehicle.
Component Location Charts helps the user find where the various items depicted on the diagram can physically be found on the vehicle. A brief
written description of the location is given, along with a reference to the component location views.
Circuit Numbering and Wire Identification
Circuit Numbering:
Ford has introduced a world-wide uniform system for circuit numbering and wire identification. The system is called Function, System-Connection, or
FSC for short.
FSC was developed mainly to assist in vehicle development and production processes, but is also helpful in troubleshooting electrical circuits.
