Fusion FWD L4-2.3L VIN Z (2007)
2. NOTE: Make sure that the brake caliper hose is not twisted.
Position the brake caliper onto the anchor plate.
3. Install the 2 brake caliper guide pin bolts.
^
To install, tighten to 26 Nm (19 ft. lbs.).
4. Using 2 new copper washers, position the brake hose and install the brake caliper flow bolt.
^
Tighten to 25 Nm (18 ft. lbs.).
5. Install the parking brake cable to the brake caliper.
^
Pull back the parking brake lever.
^
Connect the cable to the parking brake lever.
^
Install the cable conduit retaining clip.
6. Bleed the brake system.
7. Cycle the park brake several times to verify normal operation.
8. Test the brakes for normal operation.
