Fusion FWD L4-2.3L VIN Z (2007)

Page 1
background image

Compression Check: Specifications

Use the Compression Pressure Limit Chart when checking cylinder compression so that the lowest reading is within 75% of the highest reading.

Compression Pressure Limit Chart
