Fusion FWD L4-2.3L VIN Z (2007)
Headlamp Dimmer Switch: Service and Repair
Steering Column Multifunction Switch
Removal and Installation
1. NOTE: The instrument panel steering column cover is held in place by tabs that clip to the instrument panel.
Remove the instrument panel steering column cover by pulling straight outward.
2. NOTE: Release the upper steering column shroud, by pressing inward on the sides of the shroud and lifting upwards.
Remove the upper steering column shroud.
3. Release the tilt lever, remove the 3 screws and then remove the lower steering column shroud.
