Fusion FWD L4-2.3L VIN Z (2007)
11. NOTE: Fusion shown, Milan and MKZ similar.
Install the RH C-pillar trim cover and the retainers.
12. Install the RH C-pillar trim cover retainer caps.
13. Remove the restraint system diagnostic tool from the vehicle harness side of the passenger seat side air bag module electrical connector.
14. Connect the passenger seat side air bag module electrical connector and then slide and engage the seat side air bag electrical connector locking
clip.
All vehicles
