Fusion FWD L4-2.3L VIN Z (2007)
Broken wire strands in harness
1
= Wiring harness tape
2
= Wiring strand
3
= Broken strands intermittent signal
4
= Circuit insulation
Remove the tape and flex/feel each circuit for a reduction in diameter at break.
Recommended splicing method - Solder (For 16 AWG and Smaller Diameter Wire Only)
1. Disconnect battery ground cable.
2. Strip wires to appropriate length.
