Fusion FWD L4-2.3L VIN Z (2007)
CAUTION: Do not allow the brake master cylinder reservoir to run dry during the bleeding operation. Keep the brake master cylinder reservoir filled
with clean specified brake fluid. Never reuse the brake fluid that has been drained from the hydraulic system.
NOTE: When any part of the hydraulic system has been disconnected for repair or new installation, air may get into the system and cause spongy
brake pedal action. This requires bleeding of the hydraulic system after it has been correctly connected. The hydraulic system can be bled manually or
with pressure bleeding equipment.
1. Working under the instrument panel, remove the clutch master cylinder nut.
-
To install, tighten to 21 Nm (15 ft. lbs.).
2. Using a suitable suction tool, remove the brake fluid to just below the clutch reservoir hose.
3. Remove the battery and the battery tray.
4. Remove powertrain control module (PCM).
1. Disconnect the electrical connectors.
2. Remove the PCM bolts.
5. Remove the PCM bracket.
6. Disconnect the clutch master cylinder-to-clutch slave cylinder hydraulic line.
-
To install, tighten to 17 Nm (13 ft. lbs.).
