Fusion FWD L4-2.3L VIN Z (2007)
Electrical short inside the harness
1
= Solder coated wire to ground
2
= Harness protective tape
3
= Intermittent short
Solder coated wire pierced through the insulation of another circuit
4
= Grounding foil
Electrical short within the harness
Splice tape removed
1
= Intermittent short
Splice covered
2
= Wire strand
3
= Splice tape
4
= Harness tape
