Fusion FWD L4-2.3L VIN Z (2007)
Partially mated connectors
1
= Seal
2
= Displaced tab
3
= Female half
4
= Seal
5
= Intermittent contact
6
= Male half
7
= Intermittent contact
Lock may be displaced into an unlocked position; pull on the connector to verify the lock.
Deformed (enlarged) female terminals
1
= Enlarged
2
= Normal
Any probe entering the terminal may enlarge the contact spring opening creating an intermittent signal. Insert the correct mating terminal (Location A)
from the service kit and feel for a loose fit.
