Flywheel: Specifications



Flywheel Runout

0.13 mm (0.005 inch)







Transmission to Flywheel Housing Retaining Bolts 61-88 Nm (45-64 ft. lbs.)







Flywheel Housing to Block Bolts

38-52 Nm (28-38 ft. lbs.)







Engine Rear Plate-to-Flywheel Housing Bolts

17-23 Nm (13-16 ft. lbs.)







Flywheel Retaining Bolts

73-87 Nm (54-64 ft. lbs.)

-- Use a star pattern.
