Mustang V6-4.0L (2008)
Shelby GT 500 (Part 2)
Removal and Installation
1. Remove the front bumper cover.
2. Remove the 4 front bumper isolator pin-type retainers and the front bumper lower outer and upper center inner isolators.
3. Drill out the 6 front bumper spot welds.
4. Remove the front bumper bolts and the front bumper.
-
To install, tighten to 25 Nm (18 lb-ft).
5. NOTE: Spot welding the bumper is not required for installation.
To install, reverse the removal procedure.
