Mustang V8-302 5.0L CFI HO (1985)
Removal
1.
Drain the cooling system. Remove the air inlet tube.
Remove the fan shroud attaching bolts and position the shroud over the fan.
Remove the fan and spacer from the water pump shaft. Remove the shroud.
2.
Remove the air conditioner drive belt and idler pulley bracket if so equipped.
Remove the alternator drive belt.
Remove the power steering drive belt and power steering pump, if so equipped.
Remove all accessory brackets which attach to the water pump. Remove the water pump pulley.
3.
Disconnect the radiator lower hose, heater hose and water pump bypass hose at the water pump.
4.
Remove the bolts that attach the pump to the cylinder front cover. Remove the pump and gasket. Discard the gasket.
Installation
1.
Remove all gasket material from the mounting surfaces of the cylinder front cover and water pump.
2.
Position a new gasket, coated on both sides with sealer B5A-19554-A or equivalent, on the cylinder front cover; then install the pump.
3.
Install the attaching bolts and tighten to 16-24 N m (12-18 lb-ft).
