Mustang V8-302 5.0L CFI HO (1985)
Air Cleaner Housing: All Technical Service Bulletins
Air Cleaner - Abrasion From Hood Insulator Pad
Article No. 85-16-14
INSULATOR - HOOD - AIR CLEANER COVER ABRASION 5.0L UNITS BUILT PRIOR TO 5/1/85
FORD 1985 MUSTANG
Figure 11 - Air Cleaner Cover Correction
Vehicles exhibiting air cleaner cover abrasion, caused by insufficient clearance between the hood sound insulator and air cleaner covers may be
corrected by adding additional retainers to the insulator pad. See Figure 11.
1.
Obtain two (2) 352976-S32 clips and one (1) N803387-S push pin.
2.
Dimension two slots as shown in Figure 11.
