Ford Workshop Service and Repair Manuals > Mustang V8-302 5.0L CFI HO (1985) > Wiper and Washer Systems | Relays and Modules - Wiper and Washer Systems | Windshield Washer Relay | Component Information | Diagrams | Diagram Information and Instructions | Page 8744

Wiper Control Module > < Diagram Information and Instructions|Page 8743

Page 2

background image

Fig. 59 Windshield Wiper/Washer Wiring Circuit (With Interval). 1985

Wiper and Washer Systems
Relays and Modules - Wiper and Washer Systems / Windshield Washer Relay / Diagrams / Diagram Information and Instructions
Page 8744

Wiper Control Module > < Diagram Information and Instructions|Page 8743
