Ranger 2WD V6-245 4.0L VIN X SFI (1997)
Brake Rotor/Disc: Specifications
Brake Rotor/Disc
Braking Surface:
Inner Diameter
6.52 in
Outer Diameter 10.28 in
Minimum Thickness
0.964 in
Minimum Thickness is also cast into each rotor.
Runout (Maximum)
0.003 in
Swept Area
41.1 sq. ro in
Width (New)
1.023 in
Braking Surface:
Inner Diameter
6.52 in
Outer Diameter 10.28 in
Minimum Thickness
0.964 in
Minimum Thickness is also cast into each rotor.
Runout (Maximum)
0.003 in
Swept Area
41.1 sq. ro in
Width (New)
1.023 in
