Ranger 4WD L4-140 2.3L VIN A EFI (1997)
Compression Check: Specifications
(Part 1 Of 2)
(Part 2 Of 2)
The indicated compression pressures are considered within specification if the lowest reading cylinder is within 75 percent of the highest. Refer to the
chart.
