Ranger 4WD V6-245 4.0L (1991)
Engine Mount: Service and Repair
Fig. 1 Engine Mounts
1.
Remove fan shroud attaching screws, then support engine using a suitable jack and block of wood under oil pan.
2.
Remove insulator to crossmember attaching nuts and washers, then raise engine until insulator stud clears crossmember.
3.
Remove fuel pump shield to left side engine bracket attaching bolt, if necessary.
4.
Remove mount to cylinder block attaching bolts and the mount, Fig. 1.
5.
Reverse procedure to install.
