Ranger 4WD V6-245 4.0L (1991)
Compressor Clutch Coil: Service and Repair
Except FX-15 Compressor
Removal
1.
Remove clutch hub and pulley.
2.
Disconnect ground wire if equipped.
3.
Remove snap ring retaining clutch field coil on front of compressor.
4.
Remove field coil.
Installation
1.
Position clutch field coil to compressor, engaging locator pin on compressor head with hole in clutch field coil.
2.
Connect ground wire if equipped.
3.
Install snap ring to retain clutch field coil on compressor with bevel side out.
4.
Install pulley and hub on compressor.
