Ford Workshop Service and Repair Manuals > Ranger 4WD V6-245 4.0L (1991) > Instrument Panel, Gauges and Warning Indicators | Instrument Cluster / Carrier | Instrument Panel Circuit Board | Component Information | Diagrams | Diagram Information and Instructions | Page 7172

Diagram Information and Instructions|Page 7173 > < Diagram Information and Instructions|Page 7171

Page 6

background image

Instrument Panel (Standard)

Instrument Panel, Gauges and Warning Indicators
Instrument Cluster / Carrier / Instrument Panel Circuit Board / Diagrams / Diagram Information and Instructions
Page 7172

Diagram Information and Instructions|Page 7173 > < Diagram Information and Instructions|Page 7171
