Octane Adjust Shorting Bar - Revised Procedures|Page 3767 > < Octane Adjust Shorting Bar - Revised Procedures|Page 3765

Ranger 4WD V6-245 4.0L (1991)

Page 1
background image

Ignition Timing Connector: Locations

 Component Location

The SPOUT connector (SAW check connector C127) is located at the RH front of the engine compartment in front of the battery.

Octane Adjust Shorting Bar - Revised Procedures|Page 3767 > < Octane Adjust Shorting Bar - Revised Procedures|Page 3765
