Taurus AWD V6-3.5L (2009)
Removal
All engines
1. With the vehicle in NEUTRAL, position it on a hoist.
2. Remove and discard the engine oil filter.
Early build engines
3. Remove the 2 bolts and the oil filter adapter.
-
Discard the gasket and O-ring seal.
-
Clean and inspect all sealing surfaces.
Late build engines
4. Remove the 3 bolts and the oil filter adapter.
-
Discard the gasket.
-
Clean and inspect all sealing surfaces.
Installation
Late build engines
1. Using a new gasket, install the oil filter adapter and the 3 bolts.
-
Tighten to 10 Nm (89 lb-in).
Early build engines
2. Using a new gasket and O-ring seal, install the oil filter adapter.
-
Tighten the large bolt to 57 Nm (42 lb-ft).
-
Tighten the small bolt to 10 Nm (89 lb-in).
All engines
3. NOTE: Lubricate the engine oil filter gasket with clean engine oil prior to installing the oil filter.
Install a new engine oil filter.
-
Tighten to 5 Nm (44 lb-in) and then rotate an additional 180 degrees.
