Tempo FWD L4-140 2.3L HSO (VIN S) (1989)
/Page-469001.png)
Radiator Cooling Fan Control Module: Testing and Inspection
Fig. 29 Cooling Fan Controller Diagnosis - Circuit Operation Chart
Fig. 29 Cooling Fan Controller Diagnosis, Pinout - Ignition Switch Off
Fig. 29 Cooling Fan Controller Diagnosis, Pinout - Ignition Switch In Run Engine & AC Off
