Idle Speed/Throttle Actuator - Mechanical: Description and Operation
Vacuum Operated Throttle Modulator (VOTM)

Fig. 24 Vacuum operated throttle modulator (VOTM)

    The VOTM, Fig. 24, acts as a variable carburetor stop. The plunger extends when vacuum is applied.
