Canyon 2WD L4-2.9L (2008)
Ambient Temperature Sensor / Switch HVAC: Service and Repair
Ambient Air Temperature Sensor Replacement
Removal Procedure
1. Remove the air inlet grille. Refer to Grille Replacement (See: Body and Frame/Grille/Service and Repair) .
2. Disconnect the electrical connector to the ambient air temperature sensor.
3. Release the tabs (1) retaining the sensor to the radiator support bracket.
