Canyon 2WD L5-3.5L VIN 6 (2004)
![background image](/gmc/canyon_2wd/l5-3.5l_vin_6/Page-1496001.png)
Control Arm Bushing: Service and Repair
Lower Control Arm Replacement (Rear Bushing)
^
Tools Required
-
J 41805 Ball Joint Remover/Installer
Removal Procedure
1. Remove the front drive axle.
2. Remove the lower control arm.
3. Before removing the bushing, measure and record the distance from the bushing flange to the bracket. This will be the distance that the new
bushing will be installed to.
4. Remove the rear bushing. Use the J 41805.
Installation Procedure
