Canyon 4WD V8-5.3L (2009)
Sun Visor: Service and Repair
Sunshade Replacement
Removal Procedure
1. Remove the 2 screws and washers (4) securing the sunshade (1) to the roof.
2. Remove the sunshade assembly.
3. Remove the screw and washer (3) securing the sunshade retainer (2) to the roof.
4. Remove the sunshade retainer.
Installation Procedure
1. Install the sunshade retainer.
Caution: Refer to Fastener Caution (See: Service Precautions/Vehicle Damage Warnings/Fastener Caution).
