Jack: Service and Repair
Jack and Tool Stowage Container Bracket Replacement
Removal Procedure
1. Remove the jack stowage cover. Refer to Jack Stowage Cover Replacement (See: Interior Moulding / Trim/Trim Panel/Service and Repair).
2. Remove the jack from the stowage bracket by turning the jack handle to loosen the jack.
3. Remove the 2 bolts securing the jack stowage bracket to the vehicle.
Installation Procedure
1. Position the jack stowage bracket on the floor stud in the vehicle.
Caution: Refer to Fastener Caution (See: Service Precautions/Vehicle Damage Warnings/Fastener Caution).
