Canyon 4WD V8-5.3L (2009)
Suspension Travel Bumper: Service and Repair
Front Suspension
Spring Bumper Replacement (4WD, 2WD Z71)
Removal Procedure
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle (See: Wheels and Tires/Vehicle Lifting/Service and Repair).
2. Remove the jounce bumper.
Installation Procedure
1. Install the jounce bumper.
2. Lower the vehicle.
