Page 1

background image

Auxiliary Fuel Tank Selector Diagnostic Chart

Powertrain Management
Sensors and Switches - Powertrain Management
Sensors and Switches - Fuel Delivery and Air Induction / Auxiliary Fuel Tank Control <--> [Fuel Tank Selector Switch] / Technical Service Bulletins
Page 1649
