K Yukon/Denali 4WD V8-5.7L VIN R (2000)
1. Raise the headrest (1) to the full up position.
2. Insert a paper clip or a similar tool in the hole at the forward edge of the headrest retainer (2).
3. Press in on the tool to release the retainer clips.
4. Lift the headrest from the retainers.
Installation Procedure
1. Install the headrest (1) into the retainers (2).
2. Push the headrest to the full down position.
3. Pull up in order to ensure that the headrest is engaged with the headrest retainers.
Front Seat Head Restraint Retainer Replacement (Bucket)
Front Seat Head Restraint Retainer Replacement (Bucket)
Removal Procedure
1. Remove the seat back trim cover and the pad.
2. Remove the headrest from the seat back frame by squeezing the retaining tabs together at the base of the guide(s) and lifting up.
Installation Procedure
