S15/T15 2WD Jimmy V6-262 4.3L (1991)
Compressor Clutch: Service and Repair
With R-4 Compressor
Clutch Plate and Hub
Compressor Component View
Remove or Disconnect
Tools Required:
J 9399-A Thin Wall Socket
J 33027-A Clutch Hub Holding Tool
J 33013-B Hub and Drive Plate Remover
J 25008-A Compressor Holding Fixture
-
Loosen compressor mounting brackets.
1. Belt.
2. Compressor from vehicle.
