S15/T15 Jimmy 2WD L4-119 1.9L VIN A 2-BBL (1983)

Page 1
background image

Idle/Throttle Speed Control Unit: Electrical Specifications

IDLE SPEED CONTROL

Measured between terminals A& B and C & D.
