Safari Van 2WD V6-4.3L VIN X (2003)
Seat Cushion Frame Replacement
SEAT CUSHION FRAME REPLACEMENT
REMOVAL PROCEDURE
1. Remove the bucket seat from the vehicle.
2. Remove the seat cushion cover and pad.
3. Remove Lumbar support cable.
4. Remove the seat back hinge bolts from the right side of the seat frame.
5. Remove the seat back hinge bolts from the left side of the seat frame.
6. Remove the seat cushion frame from the seat back frame.
INSTALLATION PROCEDURE
1. Install the seat cushion frame to the seat back frame.
