Savana 3/4 Ton Van V8-305 5.0L VIN M SFI (2001)
Map Light Bulb: Service and Repair
DOME AND READING LAMP BULB REPLACEMENT
REMOVAL PROCEDURE
1. Gently pry on the dome lamp lens (3) with a suitable flat-bladed tool in order to disengage the retaining tabs from the dome lamp housing.
2. Remove the bulb (2) from the socket.
3. Gently pry on the map lamp lens with a suitable flat-bladed tool in order to disengage the retaining tabs from the dome lamp housing.
4. Remove the map lamp lens (3) from the dome lamp housing.
5. Remove the bulb (2) from the socket.
INSTALLATION PROCEDURE
