Savana 3500 V8-6.6L DSL Turbo VIN 6 (2007)
Negative: Service and Repair
Auxiliary Battery Negative Cable Replacement
Battery Negative Cable Replacement (Auxiliary 6.6L)
Removal Procedure
1. Raise the vehicle. Refer to Vehicle Lifting.
2. Disconnect the battery negative cable from the auxiliary battery.
3. Disconnect the negative ground leads from the frame.
4. Remove the battery negative cable from the vehicle.
Installation Procedure
1. Install the battery negative cable to the vehicle.
Notice: Refer to Fastener Notice.
2. Connect the negative ground leads to the frame.
Tighten the negative ground leads to 10 N.m (89 lb in).
3. Connect the battery negative cable to the auxiliary battery.
Tighten the bolt to 15 N.m (11 lb ft).
4. Lower the vehicle.
