Sierra 1500 2WD V8-6.0L (2007)
![background image](/gmc/sierra_1500_2wd/v8-6.0l/Page-182001.png)
Hood Sensor/Switch (For Alarm): Locations
Immobilizer Component Views
Near the Hood Latch
1 - Upper Tie Bar
2 - Hood Ajar Switch (AP3/AP8)
3 - Ambient Air Temperature Sensor - ISRVM
Hood Sensor/Switch (For Alarm): Locations
Immobilizer Component Views
Near the Hood Latch
1 - Upper Tie Bar
2 - Hood Ajar Switch (AP3/AP8)
3 - Ambient Air Temperature Sensor - ISRVM
