Front Steering Knuckle: Service and Repair

Steering Knuckle Replacement (1500)

Removal Procedure

1. Raise and support the vehicle. Refer to Vehicle Lifting.
2. Remove the tire and wheel.
3. Remove the wheel drive shaft, if equipped.
4. Remove the wheel bearing and hub assembly.
5. Remove the outer tie rod end from the knuckle.
6. Separate the upper control arm from the knuckle. Refer to Upper Control Arm Replacement.
8. Remove the knuckle from the vehicle.

Installation Procedure
