Sierra 1500 2WD V8-6.0L (2007)
Tie Rod: Service and Repair
Steering Linkage Inner Tie Rod Replacement
Steering Linkage Inner Tie Rod Replacement
Removal Procedure
Important: After removing the boot, inspect the inner tie rod for evidence of corrosion or contamination. If none is evident, continue with
the repair. If corrosion or contamination is evident, replace the steering gear.
1. Remove the steering gear boot.
Notice: Do not change the steering gear preload adjustment before moving the inner tie rod from the steering gear. Changing the steering gear
preload adjustment before moving the inner tie rod could result in damage to the pinion and the steering gear.
Notice: The pipe wrench must be placed at the valve end of the steering gear and positioned up against the inner tie rod housing. Placing the pipe
wrench in any other location will cause damage to the steering gear.
2. Place a pipe wrench on the steering gear rack (1) next to the steering linkage inner tie rod housing (2).
3. Place a wrench on the flats of the steering linkage inner tie rod housing (2).
4. Rotate the steering linkage inner tie rod housing (2) counterclockwise, while holding the steering gear rack stationary, until the steering linkage
inner tie rod separates from the steering gear rack (1).
Installation Procedure
Important: All threads must be clean prior to LOCTITE(R) application. Check the LOCTITE(R), or equivalent, container for the
expiration date. Use only enough LOCTITE(R) to evenly coat the threads.
1. Apply LOCTITE(R) 262, or equivalent, to the steering gear inner tie rod threads.
2. Attach the steering linkage inner tie rod onto the steering gear rack.
Notice: Refer to Pipe Wrench Positioning Notice.
