Sierra 1500 2WD V8-6.0L Hybrid (2010)
Oxygen Sensor: Service and Repair
Heated Oxygen Sensor - Bank 1 Sensor 1
Heated Oxygen Sensor Replacement - Bank 1 Sensor 1
Removal Procedure
Caution: Refer to Heated Oxygen and Oxygen Sensor Caution (See: Service Precautions/Heated Oxygen and Oxygen Sensor Caution).
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle (See: Maintenance/Vehicle Lifting/Service and Repair).
2. Unbolt the front propeller shaft from the front differential, if equipped with four wheel drive (4WD). Refer to Front Propeller Shaft Replacement
().
3. Remove the connector position assurance (CPA) retainer (4).
4. Disconnect the engine wiring harness electrical connector (7) from the HO2S.
5. Remove the HO2S electrical connector clip (6) from the fuel line clip.
