Sierra 1500 2WD V8-6.0L Hybrid (2010)
7. Remove the fuel pipe bracket nut (1) from the bellhousing stud, and disconnect the plastic retainers (2) from the transmission.
8. If equipped with 4-wheel drive (4WD), remove the fuel hose/pipe clip from the bracket on the transfer case.
9. Disconnect the fuel pressure sensor electrical connector.
10. Remove the EVAP canister vent solenoid clip (1) from the chassis EVAP line and secure out of the way.
11. Remove the EVAP canister vent solenoid pipe clip (2) from the chassis EVAP line.
