Sierra 1500 2WD V8-6.0L Hybrid (2010)
Differential Clutch: Service and Repair
Locking Differential Clutch Disc Assembly Disassemble (8.6 Inch Axle)
Locking Differential Clutch Disc Assembly Disassemble (8.6 Inch Axle)
1. Remove the guide clips (3).
2. Remove the clutch discs and the splined discs (2, 4-6) from the locking differential side gear (1).
