Sierra 1500 4WD V8-5.3L VIN B (2005)
Grille: Service and Repair
Grille Guard/Brush Guard Replacement
Removal Procedure
1. Remove the bolts (1) and nuts (2) from the front side brush guard (3).
2. Remove the front side brush guard from the vehicle.
3. Open the hood.
4. Remove the upper air baffle.
5. Raise the vehicle.
6. Remove the 2 lower front end guard assembly fasteners (1) from the lower support bracket.
