Sierra 1500 4WD V8-5.3L VIN Z Flex Fuel (2005)

Page 1
background image

Heater Core: Service and Repair
Heater Core Replacement

HEATER CORE REPLACEMENT (HEAT ONLY)

REMOVAL PROCEDURE

1. Remove the heater/vent module. See: Housing Assembly HVAC/Service and Repair
2. Remove the heater core cover screws.

3. Remove the heater core cover.

4. Remove the heater core.

INSTALLATION PROCEDURE

1. Install the heater core.
