Sierra 1500 4WD V8-6.0L VIN U (2006)
Wheel Bearing: Service and Repair
Front Wheel Hub, Bearing, and Seal Replacement (4WD)
Tools Required
J 45859 Axle Removal
Removal Procedure
1. Raise and support the vehicle.
2. Remove the tire and wheel.
3. Remove the rotor.
4. Remove the wheel speed sensor and brake hose mounting bracket bolt from the steering knuckle.
5. Remove the wheel drive shaft nut retaining cover.
