For sealed terminals, hand crimp the insulation wings around the seal and the cable.
8. Solder all of the hand crimp terminals excepting Micro-Pack 100.64 size. Soldering Micro-Pack 100 World terminals may damage the terminal.
Sumitomo Connectors
Sumitomo Connectors
Tools Required
J-38125 Terminal Repair Kit
Terminal Removal Procedure
1. Slide the lever lock forward while pressing down on the lever lock release tab.
2. Disconnect the connector from the component.
